Duo-Fine® II Filter Cartridges DFN310AN
Overview
Features
- Media Material: borosilicate microfiberglass with binder
- Hardware Material: Stainless steel
- O-ring/Seal/Gasket Material: Nitrile
- Removal Rating: 3µm
- Removal Efficiency: nominal
- Nominal Outer Diameter: 2.6 in 66 mm
- Nominal Length: 10 in 254 mm
- Configuration (SOE/DOE/Code7/Code3): Blank - DOE with elastomer gasket seals & end caps
- Maximum Differential Pressure: 2.4 bard
- Dirt Holding Capacity: 0
Description
The DFN310AN is a 10-inch pleated filter cartridge rated for 3 µm removal. It is constructed with microfiberglass media and a nitrile gasket to ensure both high flow rates and reliable sealing. The small-diameter fibers enable a low pressure drop, while the large surface area ensures high dirt-holding capacity and long service life.
