$92.62
  • PFT04510UEW480

Overview

Features

  • Media Material: Polypropylene
  • Hardware Material: Polypropylene
  • O-ring/Seal/Gasket Material: Ethylene Propylene Rubber
  • Removal Rating: 0.45 µm
  • Nominal Outer Diameter: 2.6 in
  • Nominal Length: 254 mm (10 in)
  • Configuration (SOE/DOE/Code7/Code3): DOE – with open end caps/gasket
  • Maximum Differential Pressure: 4.8 bard (70 psid) @ 20°C (68°F)
  • Hot Water Sanitization: 82°C (180°F) @ 1 bar (15 psig)
  • Integrity Testable: No bubble test
  • Product Use: Pre-Filtration

Description

The PFT04510UEW480 delivers reliable 0.45 µm clarification in a compact DOE industrial format. Its pleated depth media provides a large surface area to reduce initial pressure drop and extend dirt capacity, while the consistent pore structure supports reproducible retention of non-deformable particles. All polypropylene construction contains no adhesives, binders, or resins, which helps control extractables in plant water, rinses, and light process liquids. EPDM end gaskets seal securely in compatible housings for leak-tight starts and fast changeouts. Produced in a controlled environment under an ISO 9001 quality system, the element offers consistent lot-to-lot performance and can be sanitized with hot water between campaigns. Use this 10-inch model for point-of-use polishing, membrane protection, and general cleanup where space is limited and steady clarity is required.
